Functional Specifications: |
|
|
RFID Protocol: |
EPC Class1 Gen2, ISO18000-6C |
|
Frequency: |
(US)902-928MHz, (EU) 865-868MHz |
|
IC Type: |
Alien Higgs-4 |
|
Memory |
EPC 128bits, USER 128bits, TID64bits |
|
Write Cycles: |
100,000 times |
|
Functionality: |
Read/Write |
|
Data Retention: |
Up to 50 Years |
|
Applicable Surface: |
Metal Surfaces |
|
Read Range: By fixed reader |
680cm - (US) 902-928MHz, on metal; 400cm- (US) 902-928MHz,off metal. 350cm- (EU) 865-868MHz, off metal. |
|
Read Range: By handheld reader |
530cm - (US) 902-928MHz, on metal; 270cm - (US) 902-928MHz, off metal. 220cm- (EU) 865-868MHz, off metal. |
|
Warranty: |
1 Year |
|
Physical Specifications: |
|
|
Size: |
42x15mm, (Hole: D4mmx2) |
|
Thickness: |
2.1mm without IC bump, 2.8mm with IC bump |
|
Material: |
High Temperature Material |
|
Color: |
Black |
|
Mounting Methods |
Adhesive, Screw |
|
Weight: |
3.5g |
|
Environmental: |
|
|
IP Rating: |
IP68 |
|
Storage Temperature: |
-55°С~200°С (280°С for 50 minutes, 250°С for 150minutes) |
|
Operatino Temperature: |
-40°С ~150°С (working 10hours in 180°С) |
